Gravely ZT X Series

$4,299.00 – $4,499.00

Compare
SKU: 949001-1-2-2 Categories: , , Brand:

Description

Features

One-piece, Fully-Welded Tubular Chassis

Influenced by our commercial applications, this all-new chassis displays strength and durability with its closed tube frame rails and fully welded construction techniques.

New X-Factor® 11-gauge Fabricated Deck

All new 4 1/2 inch-deep deck optimizes airflow, and its reinforced sloped nose allows more room for grass to stand up ahead of the cutting chamber. Caged anti-scalp wheels make your lawn less susceptible to damage from minor bumps and scrapes.

Hydro-Gear® Serviceable EZT® Transaxles

Optimized cooling to ensure smooth running for years to come. New service ports allow oil changes to help extend the life of your machine.



ZT X 42 KAWASAKI

ZT X 48 KAWASAKI

ZT X 52 KAWASAKI
Model Number 918008 918009 918011
Power Train
Engine Kawasaki® FR651V Kawasaki® FR651V Kawasaki® FR691V
Horsepower 21.5 21.5 23
Engine Displacement 44.3 in / 726 cc 44.3 in / 726 cc 44.3 in / 726 cc
Fuel System Gas Gas Gas
Fuel Capacity 3.5 gal / 13.2 ltr 3.5 gal / 13.2 ltr 3.5 gal / 13.2 ltr
Drive System Hydro-Gear® Serviceable EZT® Transaxles Hydro-Gear® Serviceable EZT® Transaxles Hydro-Gear® Serviceable EZT® Transaxles
Transmission Type Hydrostatic Hydrostatic Hydrostatic
Brake Type Integrated Parking Brake Integrated Parking Brake Integrated Parking Brake
Driver Position Sit Sit Sit
Ground Speed Forward 7 mph / 11.3 kph 7 mph / 11.3 kph 7 mph / 11.3 kph
Ground Speed Reverse 3 mph / 4.8 kph 3 mph / 4.8 kph 3 mph / 4.8 kph
Wheels Front 11.0 x 6.0 in – 5.0 in (27.9 x 15.2 cm – 27.9 cm) 11.0 x 6.0 in – 5.0 in (27.9 x 15.2 cm – 27.9 cm) 11.0 x 6.0 in – 5.0 in (27.9 x 15.2 cm – 27.9 cm)
Wheels Rear 20.0 x 8.0 in – 8.0 in (50.8 x 20.3 cm – 20.3 cm) 20.0 x 10.0 in – 8.0 in (50.8 x 25.4 cm – 20.3 cm) 20.0 x 10.0 in – 8.0 in (50.8 x 25.4 cm – 20.3 cm)
Electric
Battery Capacity 190 CCA 190 CCA 190 CCA
Number of Batteries 1 1 1
Battery Voltage 12 12 12
Battery Type AGM AGM AGM
Battery Size U1 Compatible U1 Compatible U1 Compatible
Deck
Deck Size 42 in / 106.7 cm 48 in / 121.9 cm 52 in / 132.1 cm
Coverage Hour 2.9 acres / 1.2 hectares 3.4 acres / 1.4 hectares 3.6 acres / 1.5 hectares
Spindle Type Mechanical Mechanical Mechanical
Deck Material 11 ga 11 ga 11 ga
Deck Construction Fabricated X-Factor® Fabricated X-Factor® Fabricated X-Factor®
Discharge Configuration Side Side Side
Cutting Height Min 1.5 in / 3.8 cm 1.5 in / 3.8 cm 1.5 in / 3.8 cm
Cutting Height Max 4.5 in / 11.4 cm 4.5 in / 11.4 cm 4.5 in / 11.4 cm
Cutting Width 42 in / 106.7 cm 48 in / 121.9 cm 52 in / 132.1 cm
Dimensions
Weight (assembled) 667 lb 679 lb 695 lb
Length 74.5 in / 189.2 cm 74.5 in / 189.2 cm 74.5 in / 189.2 cm
Width (Chute Up) 45.1 in / 114.6 cm 51.1 in / 129.8 cm 55.6 in / 141.2 cm
Width (Chute Down) 56.2 in / 142.7 cm 62.3 in / 158.2 cm 66.7 in / 169.4 cm
