Gravely PRO-TURN® 500 Series

Price range: $14,299.00 through $16,999.00

Compare
SKU: N/A Categories: , , Brand:

Description

Features

Comfortable Seat

Isolated mounting absorbs more shock while the high-back seat with lumbar support and padded armrests deliver cushioned comfort.

Fully Welded Tubular Frame

Rugged and strong, its wide front rail distributes weight for superior balance.

Parker HTG Transaxles

Parker HTG transaxles deliver a top speed of 15mph and have a 16cc pump. Filters are easily accessed from the rear for maintenance.



PRO-TURN 552 KAWASAKI

PRO-TURN 560 KAWASAKI

PRO-TURN 572 KAWASAKI
Model Number 992510 992511 992512
Power Train
Engine Kawasaki® FX850V Kawasaki® FX921V Kawasaki® FX921V
Horsepower 27 31 31
Engine Displacement 52 in / 852 cc 61 in / 999 cc 61 in / 999 cc
Transmission Type Hydrostatic Hydrostatic Hydrostatic
Fuel System Gas Gas Gas
Fuel Capacity 12.5 gal / 47.3 ltr 12.5 gal / 47.3 ltr 12.5 gal / 47.3 ltr
Drive System Hydrostatic Hydrostatic Hydrostatic
Brake Type Lever Activated Parking Lever Activated Parking Lever Activated Parking
Driver Position Sit Sit Sit
Ground Speed Forward 15 mph / 24.1 kph 15 mph / 24.1 kph 15 mph / 24.1 kph
Ground Speed Reverse 6 mph / 9.7 kph 6 mph / 9.7 kph 6 mph / 9.7 kph
Wheels Front 15.0 x 6.0 in – 6.0 in (38.1 x 15.2 cm – 38.1 cm) 15.0 x 6.0 in – 6.0 in (38.1 x 15.2 cm – 38.1 cm) 15.0 x 6.0 in – 6.0 in (38.1 x 15.2 cm – 38.1 cm)
Wheels Rear 26.0 x 12.0 in – 12.0 in (66.0 x 30.5 cm – 30.5 cm) 26.0 x 12.0 in – 12.0 in (66.0 x 30.5 cm – 30.5 cm) 26.0 x 12.0 in – 12.0 in (66.0 x 30.5 cm – 30.5 cm)
Front Wheel Track 42.3 in 42.3 in 51.9 in
Rear Wheel Track 55 in / 139.7 cm 55 in / 139.7 cm 55 in / 139.7 cm
Electric
Battery Capacity 300 CCA 300 CCA 300 CCA
Number of Batteries 1 1 1
Battery Voltage 12 12 12
Battery Type Lead Acid – Maintenance Free Lead Acid – Maintenance Free Lead Acid – Maintenance Free
Battery Size U1 U1 U1
Deck
Deck Size 52 in / 132.1 cm 60 in / 152.4 cm 72 in / 182.9 cm
Coverage Hour 7.8 acres / 3.2 hectares 9 acres / 3.6 hectares 10.8 acres / 3.2 hectares
Spindle Type Mechanical Mechanical Mechanical
Deck Material 7 ga 7 ga 7 ga
Deck Construction Fabricated X-Factor® 3 Fabricated X-Factor® 3 Fabricated X-Factor® 3
Discharge Configuration Side Side Side
Cutting Height Min 1 in / 2.5 cm 1 in / 2.5 cm 1 in / 2.5 cm
Cutting Height Max 5.5 in / 14 cm 5.5 in / 14 cm 5.5 in / 14 cm
Cutting Width 52 in / 132.1 cm 60 in / 152.4 cm 72 in / 182.9 cm
Dimensions
Weight (assembled) 1447 lb 1487 lb 1580 lb
Length 84 in / 213.4 cm 84 in / 213.4 cm 86.2 in / 218.9 cm
Width 52 in / 132.1 cm 60 in / 152.4 cm 72 in / 182.9 cm
Width (Chute Up) 51 in / 129.5 cm 63 in / 160 cm 75 in / 190.5 cm
Width (Chute Down) 63 in / 160 cm 75 in / 190.5 cm 87 in / 221 cm



PRO-TURN 560 KAWASAKI FX1000 EFI

PRO-TURN 572 KAWASAKI FX1000 EFI
Model Number 992530 992531
Power Train
Engine Kawasaki® FX1000 EFI Kawasaki® FX1000 EFI
Horsepower 38.5 38.5
Engine Displacement 61 in 61 in
Power Brand N/A
Fuel System Gas Gas
Fuel Capacity 13.4 gal / 50.7 ltr 13.4 gal / 50.7 ltr
Drive System Hydrostatic Hydrostatic
Brake Type Lever Activated Parking Lever Activated Parking
Driver Position Sit Sit
Ground Speed Forward 15 mph / 24.1 kph 15 mph / 24.1 kph
Ground Speed Reverse 6 mph / 9.7 kph 6 mph / 9.7 kph
Wheels Front 15.0 x 6.0 in – 6.0 in (38.1 x 15.2 cm – 38.1 cm) 15.0 x 6.0 in – 6.0 in (38.1 x 15.2 cm – 38.1 cm)
Wheels Rear 26.0 x 12.0 in – 12.0 in (66.0 x 30.5 cm – 30.5 cm) 26.0 x 12.0 in – 12.0 in (66.0 x 30.5 cm – 30.5 cm)
Deck
Deck Size 60 in / 152.4 cm 60 in / 152.4 cm
Coverage Hour 9 acres / 3.6 hectares 10.8 acres / 4.4 hectares
Spindle Type Electric Electric
Deck Material 7 ga 7 ga
Deck Construction Fabricated X-Factor® 3 Fabricated X-Factor® 3
Discharge Configuration Side Side
Cutting Height Min 1 in / 2.5 cm 1 in / 2.5 cm
Cutting Height Max 5.5 in / 14 cm 5.5 in / 14 cm
Cutting Width 60 in / 152.4 cm 72 in / 182.9 cm
Dimensions
Weight (assembled) 1506 lb 1609 lb
Length 84 in / 213.4 cm 86.2 in / 218.9 cm
